Centralize analog &
digital measurements
![BLOC 7](https://static.wixstatic.com/media/084c74_37bf1c87ac6a438093bbb96955ae3afc~mv2.jpg/v1/fill/w_391,h_280,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/BLOC%207.jpg)
![Bloc-7.jpg](https://static.wixstatic.com/media/084c74_8c1b971f117149c7b83bf1191546312e~mv2.jpg/v1/fill/w_389,h_215,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/Bloc-7.jpg)
![cable-can.jpg](https://static.wixstatic.com/media/084c74_f991d9aa555047149e004b69677d5739~mv2.jpg/v1/fill/w_175,h_130,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/cable-can.jpg)
The Bloc 7 is a measuring bloc integrating 6 universal inputs.
They allow the measurement of:
- voltages between 0 and 30 VDC in order to acquire analog measurements (battery voltage)
- voltages between 0-10 VDC (sensor voltage).
- water levels (fresh water, gray water, black water, fuel) by configuring the
input as a current generator.
Bloc 7 also integrates 3 digital inputs to view the state of sensors (bilge pump).
Via the LIN Bus you can add up to 6 IBS sensors.
If bloc 7 is connected to a Navicolor screen, all measurements can be viewed from the touchscreen.
The bloc 7 may be configured in 3 different ways:
- from a Navicolor,
- with a PC using the MULTICOM software and the CAN/USB interface,
- from a configuration interface of the wifi server.
MEASURE AND DISPLAY
INFORMATION
![capteur-courant.jpg](https://static.wixstatic.com/media/084c74_4fd2a3cbbd42491497ccde931b48eb9f~mv2.jpg/v1/crop/x_126,y_100,w_395,h_284/fill/w_74,h_50,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/capteur-courant.jpg)
Current sensor
![capteur-eau.jpg](https://static.wixstatic.com/media/084c74_2e5c5147c9694b0d840f6b2c3a4a7ab0~mv2.jpg/v1/fill/w_105,h_75,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/capteur-eau.jpg)
Water sensor
![acquisition-donnees.jpg](https://static.wixstatic.com/media/084c74_13f22e48e8cf4a69a3758290d303a911~mv2.jpg/v1/fill/w_110,h_83,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/acquisition-donnees.jpg)
Acquisition of digital
& analog values
![configuration.jpg](https://static.wixstatic.com/media/084c74_0e60d3fbe03c45bda7b3c04aa4ef4605~mv2.jpg/v1/fill/w_95,h_66,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/configuration.jpg)
Quick setup
• 6 configurable analog inputs :
0-30VDC (battery voltage)
0-10V (current sensor)
0-180Ω (fresh water or fuel sensor)
30-240 Ω (grey water sensor)
• 3 digital inputs :
1 input (+) type pnp
2 inputs (-)
• BUS LIN
